Infrastructure |
|
| |
| Shop floor for CNC machine |
| |
 |
- Gee Dee Weiler CNC chucker Lathe
Max Capacity :Dia 135mm, Length : 110mm
- Lokesh TL-20 CNC Lathe
Max Capacity : Dia 228mm, Length 300mm
- Ace Jobber XL CNC
|
|
| |
| |
| Shop floor for conventional machine |
| |
 |
- Traub A/25
- Traub A/32
- Traub A/42
- Thread Rolling
- Center less Grinding M/c
- Milling Machine
- Gee Dee Weiler Capstan Lathe
- Drilling cum Tapping M/c
- Center lathe– S.I.G.T tool & cutter grinder with all types of attachments
|
| Shop floor for conversional machine |
|
|
| |
| |
Standards room for Calibration and precision instrument |
| |
 |
-
Tesa Digital Micrometer, 0-25.
-
Tesa Digital Micrometer, 25-50.
-
Surface Table (Alfa – Zero Grade), 1000X1000mm.
-
Slip gauges (Micronix – Zero Grade).
- Digital height Vernier (Mitutoyo).
- Cp And Wcp for Screw Ring gauge calibration – All Major size.
- Hygrometer.
- Digital Micrometer (Mitutoyo), 0-25.
- Digital Micrometer (Mitutoyo), 25-50.
- Plating tester (Micro Test).
- Finish tester (Mitutoyo).
- Profile projector (Mitoyo – 10X).
- Slip gauges (Grade 3).
- Digital height Vernier.
- Hardness Tester.
|
|
| |
| |
| Storages |
| |
 |
- Tesa Digital Micrometer, 0-25.
- Tesa Digital Micrometer, 25-50.
- Surface Table (Alfa – Zero Grade), 1000X1000mm.
- Slip gauges (Micronix – Zero Grade).
- Digital height Vernier (Mitutoyo).
- Cp And Wcp for Screw Ring gauge calibration – All Major size
- Hygrometer.
- Vernier calipers - Digital / Analog.
- Bore micrometer, Depth Micrometer, Blade Micrometers, Micrometer.
- Dial gauge – ID/ID Groove, Dial caliper, Dial gauge, Bore dial gauge, Air Gauge(Baker).
- Gap Gauge , Plain plug gauge , Slip gauge , Plain ring gauge .
- Screw ring gauge, Screw Plug gauge.
- Position Gauges , Flush Pin Gauges
|
| Tools and gauges stores |
 |
| Final Inspection and Despatch |
 |
| Raw material Storage |
| |
|
| |
| Gallery |
| |
 |
 |
| Total buildup area : 4500 Sft |
Conference Hall |
|
|
|
|
 |
 |
|
 |
|
